Volvo VNL Radiator with Frame - Complete Drop-In Assembly (2008-2025) - Replaces 22234461
Regular price
$584.61
Couldn't load pickup availability
- Ships same dayOn in-stock orders
- 30-day money-backShop with confidence
- Secure checkoutEncrypted payment
We accept
Fitment
Fits these trucks
Volvo VNL/VNM/CT/CV Series (2008-2025)Mack Pinnacle (2007-2025)Mack Vision/Granite Series (2008-2025)
Always confirm your year, make & model before ordering.
Part numbers
OEM & interchange numbers
20 cross-refs22234461 209565521 21593038 20956564 85111314 21146403 23017335 23459369 8172F S8172 VOL03F M5734100 2MF549M ABPN2020014608 Automann 85111310 Mack 21298076 Mack 21504536 Mack 21504548 Mack 20014608 Mack 20956552
Direct 1-to-1 replacement for every number above. Tap any number to copy.
Overview
Stop wasting time swapping rusted, fatigued mounting hardware and get your rig back on the road with this Volvo VNL Radiator with Frame by FleetPro Parts & Tires. Specifically designed for the 2008–2025 Volvo VNL and Mack Pinnacle series, this "all-in-one" solution features a high-capacity 2-row aluminum core pre-mounted in a heavy-duty steel frame. By choosing a framed unit, you eliminate the risk of core damage during transfer and save hours of labor costs. We stock these heavily right here in our Hanover Park, Illinois warehouse to ensure lightning-fast shipping across the Midwest and nationwide.
Save Labor and Prevent Stress: The Volvo VNL Radiator with Frame Advantage
This Volvo VNL Radiator with Frame is engineered to withstand the punishing vibrations of long-haul trucking. The reinforced steel frame acts as a protective exoskeleton, preventing chassis flex from cracking the aluminum core or compromising the plastic tank bonds. Note: This premium assembly includes an integrated transmission oil cooler with 11-1/2" centers, ensuring your drivetrain remains protected even under maximum load in 2026's demanding haul schedules.
At FleetPro, we prioritize cooling components that offer a professional-grade alternative to expensive dealer parts without sacrificing durability. This complete framed unit serves as a direct replacement for major OEM numbers including 22234461 and 209565521. Replacing just the core often leads to premature failure if the old frame is warped; do the job right the first time with a FleetPro framed assembly.
Vehicle Fitment & Compatibility
This framed radiator assembly is a guaranteed fit for the following heavy-duty applications:
- Volvo: VNL, VNM, CT, CV Series (2008–2025)
- Mack: Pinnacle (2007–2025)
- Mack: Vision, Granite Series (2008–2025)
Direct Replacement & Cross-Reference Numbers:
This assembly serves as a direct exact-fit replacement for the following part numbers:
- Major OEM: 22234461, 209565521, 21593038, 20956564, 85111314, 21146403, 23017335, 23459369
- Industry Cross: 8172F, S8172, VOL03F, M5734100, 2MF549M, ABPN2020014608
Technical Specifications
Core Dimensions 40-5/8" Height x 34-1/4" Width Construction Aluminum Core / Plastic Tanks / Steel Frame Core Depth 2" (High-Efficiency 2-Row) Inlet/Outlet 2-1/2" (Upper Left / Lower Right) Oil Cooler Internal (11-1/2" Centers) Warranty 1-Year Limited Warranty
Key features
- Complete Drop-In Assembly: Comes pre-mounted with the heavy-duty reinforcement frame, saving you hours of labor and the frustration of transferring old, fatigued hardware.
- Vibration & Stress Protection: The included steel frame prevents chassis flex and heavy road vibrations from cracking the aluminum core, maximizing your cooling system's lifespan.
- Integrated Oil Cooler: Features a built-in transmission oil cooler with 11-1/2" centers to regulate drivetrain temperatures under heavy commercial loads.
- Direct OEM Match: Precision-engineered to directly replace OEM numbers 22234461, 209565521, and 21593038 for a seamless, factory-style installation.
- 1-Year Warranty: Backed by a comprehensive 1-Year Limited Warranty, giving owner-operators and fleet managers peace of mind for the miles ahead.
Specifications
Core Dimensions
40-5/8 in Height x 34-1/4 in Width
Construction
Aluminum Core / Plastic Tanks / Steel Frame
Core Depth
2 in (High-Efficiency 2-Row)
Inlet/Outlet
2-1/2 in (Upper Left / Lower Right)
Oil Cooler
Internal (11-1/2 in Centers)
Warranty
1-Year Limited Warranty
Questions
Will this fit my truck?
This part fits Volvo VNL/VNM/CT/CV Series (2008-2025), Mack Pinnacle (2007-2025), Mack Vision/Granite Series (2008-2025). Always confirm your year, make and model before ordering.
What part numbers does it replace?
Yes. It is a direct replacement that interchanges with 22234461, 209565521, 21593038, 20956564, 85111314, 21146403, 23017335, 23459369, 8172F, S8172, VOL03F, M5734100, 2MF549M, ABPN2020014608, Automann 85111310, Mack 21298076, Mack 21504536, Mack 21504548, Mack 20014608, Mack 20956552.
How fast does it ship?
In-stock orders placed before 12 PM Central on business days ship the same day from our Hanover Park, IL warehouse, and typically arrive in 2 to 5 business days anywhere in the USA.
What's your return policy?
Unused items in original packaging can be returned within 30 days, backed by our 30-day money-back guarantee. If we ship the wrong part, we cover the return label and send the correct one.
