ABS Wheel Speed Sensor Kit - Straight Head 18in Cable - Haldex AL1027196 364528001 577.AL1027196

Not every ABS sensor position needs a long lead, and buying one that is too long is just as wrong as buying one that is too short. This ABS Wheel Speed Sensor Kit distributed by FleetPro Parts & Tires is the short-lead version, built with a straight head and an 18in cable, and supplied with the sensor clip and grease. When the head corrodes or the lead is damaged, the ABS/EBS control unit loses that wheel's speed signal, stores a fault code and drops out of ABS and stability-control operation. Manufactured by Automann to Fleet Standard specifications, we stock these heavily right here in our Hanover Park, Illinois warehouse to ensure lightning-fast shipping for fleets, diesel repair shops, and owner-operators nationwide.

Short Lead, Clean Install: The 18in Straight-Head Sensor Advantage

The 18in cable is what defines this kit. It is the right choice only where the sensor being replaced runs a short lead, so measure before you order. Where it belongs, the short cable is the cleaner repair: there is no excess lead to coil, tie off or leave hanging near the tire and the suspension, and the fewer inches of cable exposed at the wheel end, the less there is to chafe through over the life of the sensor.

The straight sensor head goes into the wheel-end bore the same way the original did, and the included sensor clip is what holds it at the correct depth once it is in. The grease that ships with it keeps the sensor seating and serviceable instead of corroding into the bore. This is an Automann Fleet Standard kit for Haldex ABS applications on heavy-duty air brake systems, where correct sensor signal is critical for ABS/EBS and stability control operation.

At FleetPro Parts & Tires, we know the right sensor is the one with the right cable on it. This kit is a direct replacement for highly searched industry numbers including Haldex AL1027196, 364528001 and HDXAL1027196.

Vehicle Fitment & Compatibility

This ABS wheel-speed sensor kit is intended for the following commercial applications:

• Application: Haldex ABS wheel-speed sensor circuits
• System: Heavy-duty air brake systems with ABS/EBS and stability control
• Location: Wheel end, straight sensor head
• Cable Reach: 18in, short-lead position
• Component Group: Brake System / ABS Sensors

Direct Replacement & Cross-Reference Numbers:

This Automann ABS sensor kit serves as a direct replacement for the following part numbers:

• Haldex Interchange: 364528001, AL1027196, HDXAL1027196
• Automann Distributor #: 577.AL1027196

Technical Specifications

• Component Type: ABS Wheel Speed Sensor Kit
• Head Style: Straight
• Cable Length: 18in
• Includes: Sensor Clip and Grease
• Application: Haldex
• Weight: 0.25 lbs
• Package Dims: 10.437 x 8 x 0.812 in
• Product Level: Fleet Standard Aftermarket
• Brand: Automann (Distributed by FleetPro Parts & Tires)
