Blue Service Gladhand Air Hose Connector - 3/8in NPT SAE J318 - F-036AS115
Regular price
$2.99
Couldn't load pickup availability
- Ships same dayOn in-stock orders
- 30-day money-backShop with confidence
- Secure checkoutEncrypted payment
We accept
Fitment
Fits these trucks
Universal - Class 6 through Class 8 trucks and semi-trailersTractor-trailer service (blue) control air lineUniversal, 3-in-1 air linesRear of the tractor or nose of the trailer
Always confirm your year, make & model before ordering.
Overview
Get the service line sealing again with this blue service gladhand air hose connector from FleetPro Parts & Tires. This is the quick-connect coupler that joins the tractor and trailer service (control) air line, the line that carries the foot-brake signal back to the trailer brakes. When the casting cracks, the seal seat wears, or the hose end gets chafed on a 3-in-1 air line set, you get a hiss at the coupling, a soft trailer application and a write-up waiting to happen. Replacing the hose-end connector repairs the assembly instead of scrapping a whole line set. We stock these heavily right here in our Hanover Park, Illinois warehouse to ensure lightning-fast shipping for fleets, trailer repair shops, and owner-operators nationwide.
Leak-Free Control Line: The Blue Service Gladhand Advantage
This connector mates to any standard SAE J318 gladhand and seals with a full-face rubber gladhand seal, so the joint holds pressure through road vibration instead of weeping every time the tractor twists against the trailer. The cast aluminum body takes the abuse of being dropped on a catwalk, dragged across a deck plate and coupled thousands of times, and the 3/8in NPT female rear port threads straight onto standard air line hardware with no adapters to chase.
The blue color and the offset locking lugs are the industry standard that keeps the service line from being cross-coupled to the red emergency line, a mix-up that leaves the trailer brakes fighting the driver. It installs at the rear of the tractor or on the nose of the trailer and couples to the mating service gladhand on the connecting unit. At FleetPro Parts & Tires, we know an air brake repair is only finished when the coupling stops leaking, so order the matching red emergency connector at the same time when you are rebuilding both ends of a line set.
Vehicle Fitment & Compatibility
This universal-application service gladhand is intended for the following commercial use:
- Make/Model: Universal - Class 6 through Class 8 trucks and semi-trailers
- System: Tractor and trailer air-brake systems, service (blue) control line
- Mounting: Rear of the tractor or nose of the trailer, coupling to the mating service gladhand on the connecting unit
- Air Lines: Universal, 3-in-1 air lines
- Component Group: Air Brake & Wheel / Gladhands & Accessories
Direct Replacement & Cross-Reference Numbers:
Order this service-line connector by its FleetPro part number:
- FleetPro Part #: F-036AS115
Technical Specifications
- Component Type: Service (Control) Line Gladhand Connector
- Line: Service (control)
- Color: Blue
- Rear Port Thread: 3/8in NPT (female)
- Body Material: Cast aluminum
- Seal: Full-face rubber gladhand seal
- Coupling Standard: SAE J318
- Brand: FleetPro (Distributed by FleetPro Parts & Tires)
Key features
- Correct Blue Service Coupler: The blue body and offset locking lugs keep the control line from being cross-coupled to the red emergency line.
- Full-Face Rubber Seal: A full-face gladhand seal holds the joint tight through road vibration instead of weeping every time the tractor twists.
- Cast Aluminum Body: Stands up to being dropped, dragged and coupled thousands of times at the back of the cab.
- 3/8in NPT Female Port: Threads straight onto standard air line hardware, so there are no adapters to hunt down at the parts counter.
- Repairs the Line Set: Replacing a chafed hose end fixes a 3-in-1 air line assembly instead of scrapping the entire set.
Specifications
Component Type
Service (Control) Line Gladhand Connector
Line
Service (control)
Color
Blue
Rear Port Thread
3/8in NPT (female)
Body Material
Cast aluminum
Seal
Full-face rubber gladhand seal
Coupling Standard
SAE J318
Questions
Will this fit my truck?
This part fits Universal - Class 6 through Class 8 trucks and semi-trailers, Tractor-trailer service (blue) control air line, Universal, 3-in-1 air lines, Rear of the tractor or nose of the trailer. Always confirm your year, make and model before ordering.
How fast does it ship?
In-stock orders placed before 12 PM Central on business days ship the same day from our Hanover Park, IL warehouse, and typically arrive in 2 to 5 business days anywhere in the USA.
What's your return policy?
Unused items in original packaging can be returned within 30 days, backed by our 30-day money-back guarantee. If we ship the wrong part, we cover the return label and send the correct one.
