Brake S-Camshaft LH - Fruehauf Pro-Par 16-1/2in 1.625in-37 Spline - Replaces Meritor 2210R2488 Euclid E1563 121.371604.01
Regular price
$30.66
Couldn't load pickup availability
- Ships same dayOn in-stock orders
- 30-day money-backShop with confidence
- Secure checkoutEncrypted payment
We accept
Fitment
Fits these trucks
Fruehauf Pro-Par trailer axles with 16-1/2in brakesLeft-hand (LH) side, sold per side37 splines, 1.625in diameter, 16.125in longRebuild with repair kit 110.2101 or 110.2102
Always confirm your year, make & model before ordering.
Part numbers
OEM & interchange numbers
7 cross-refsEuclid E1563 Fruehauf AXA000420001 Haldex CS41528 Meritor 2210R2488 Meritor 2210X6316 Meritor R607011 Spicer 17-621
Direct 1-to-1 replacement for every number above. Tap any number to copy.
Overview
Put the bite back in a trailer's foundation brakes with this Brake S-Camshaft distributed by FleetPro Parts & Tires. Manufactured by Automann for Fruehauf Pro-Par axles with 16-1/2in brakes, this left-hand cam turns slack adjuster motion into brake shoe spread at the wheel end. A cam with a worn head profile or rounded splines gives up brake torque long before the linings are gone, and it is exactly what an inspector finds sitting behind a long pushrod stroke. We stock these heavily right here in our Hanover Park, Illinois warehouse to ensure lightning-fast shipping for fleets, trailer repair shops, and owner-operators nationwide.
Trailer Braking Restored: The Fruehauf Pro-Par S-Camshaft Advantage
This left-hand (LH) camshaft runs 16.125in long with a 1.375in head and 37 splines on a 1.625in diameter โ the exact combination the Fruehauf Pro-Par axle expects behind a 16-1/2in brake. Get any one of those three wrong and the slack adjuster either will not seat on the spline or runs out of usable travel, so match length, head and spline count before you order.
Camshafts are sold per side, so this covers the LH position only; order the right-hand cam for the opposite end of the axle. Rebuild the cam tube while the drum is off โ repair kits 110.2101 and 110.2102 carry the bushings and hardware, and a fresh cam dropped into worn bushings simply repeats the failure you just paid to fix.
At FleetPro Parts & Tires, we know that on a trailer the brakes are the entire safety story. This Automann camshaft is a direct replacement for highly searched industry numbers including Meritor 2210R2488, Euclid E1563, Haldex CS41528, Fruehauf AXA000420001 and Spicer 17-621.
Vehicle Fitment & Compatibility
This heavy-duty aftermarket S-camshaft is intended for the following commercial application:
- Make/Model: Fruehauf Pro-Par trailer axles
- Brake Size: 16-1/2in
- Position: Left-hand (LH), sold per side
- Spline: 37 splines, 1.625in diameter
- Repair Kits: 110.2101 / 110.2102
- Component Group: Air Brake Foundation / S-Camshafts
Direct Replacement & Cross-Reference Numbers:
This Automann S-camshaft serves as a direct replacement for the following part numbers:
- Euclid Interchange: E1563
- Fruehauf Interchange: AXA000420001
- Haldex Interchange: CS41528
- Meritor Interchange: 2210R2488, 2210X6316, R607011
- Spicer Interchange: 17-621
- Automann Distributor #: 121.371604.01
Technical Specifications
- Component Type: Brake S-Camshaft
- Side: Left (LH)
- Fits: Fruehauf Pro-Par Axles with 16-1/2in Brakes
- Brake: 16-1/2in
- Splines: 37 splines, 1.625in diameter
- Head: 1.375in
- Length: 16.125in
- Repair kits: 110.2101 / 110.2102
- Weight: 12.5 lbs
- Package Dims: 22 x 4.5 x 2.75 in
- Product Level: Fleet Standard Aftermarket
- Brand: Automann (Distributed by FleetPro Parts & Tires)
Key features
- Exact Pro-Par Geometry: 16.125in length, 1.375in head and 37 splines on 1.625in match the Fruehauf Pro-Par axle behind 16-1/2in brakes.
- Restores Trailer Brake Torque: A fresh head profile spreads the shoes fully again, recovering the stopping power a worn cam quietly gives away.
- Cures Long Pushrod Stroke: Undamaged splines let the slack adjuster seat and hold, so the stroke stops creeping out between adjustments.
- Rebuild-Ready: Pairs with repair kits 110.2101 and 110.2102 so the bushings and hardware go in with the new cam, not after it.
- True Left-Hand Part: Sold per side as a genuine LH camshaft, so the hand is right the first time instead of forced into place.
Specifications
Component Type
Brake S-Camshaft
Side
Left (LH)
Fits
Fruehauf Pro-Par Axles with 16-1/2in Brakes
Brake
16-1/2in
Splines
37 splines, 1.625in diameter
Head
1.375in
Length
16.125in
Repair kits
110.2101 / 110.2102
Application
Fruehauf Pro-Par trailer axles
Weight
12.5 lbs
Package Dims
22 x 4.5 x 2.75 in
UPC
889626008009
Product Level
Fleet Standard Aftermarket
Questions
Will this fit my truck?
This part fits Fruehauf Pro-Par trailer axles with 16-1/2in brakes, Left-hand (LH) side, sold per side, 37 splines, 1.625in diameter, 16.125in long, Rebuild with repair kit 110.2101 or 110.2102. Always confirm your year, make and model before ordering.
What part numbers does it replace?
Yes. It is a direct replacement that interchanges with Euclid E1563, Fruehauf AXA000420001, Haldex CS41528, Meritor 2210R2488, Meritor 2210X6316, Meritor R607011, Spicer 17-621.
How fast does it ship?
In-stock orders placed before 12 PM Central on business days ship the same day from our Hanover Park, IL warehouse, and typically arrive in 2 to 5 business days anywhere in the USA.
What's your return policy?
Unused items in original packaging can be returned within 30 days, backed by our 30-day money-back guarantee. If we ship the wrong part, we cover the return label and send the correct one.
