Freightliner Drive Axle Flange Gasket - Eaton 6823 Volvo/White 476075 180.10610

Seal the drive axle flange right the first time with this Drive Axle Flange Gasket distributed by FleetPro Parts & Tires. It sits at the drive axle flange joint on Freightliner and other Class 8 axles, and it is the cheapest part on the job that decides whether that joint stays dry. A crushed, cracked or re-used gasket weeps lube at the flange, streaks the wheel, and puts the same wheel end back on the rack a month later. We stock these heavily right here in our Hanover Park, Illinois warehouse to ensure lightning-fast shipping for fleets, diesel repair shops, and owner-operators nationwide.

A Dry Flange Joint: The Drive Axle Flange Gasket Advantage

This gasket is manufactured to OE specification, so the bolt pattern and the sealing face match what came off the truck and the flange pulls down flat instead of fighting you. That matters more than it sounds. A flange that seals unevenly does not simply drip - it lets lube creep out toward the wheel and turns a routine axle shaft pull into a much bigger cleanup.

Installation is simple and unforgiving in equal measure. Clean both sealing surfaces before the new gasket goes on, then torque the flange bolts to spec in sequence so the clamp load is even the whole way around. At 0.03 lbs this is a part worth keeping a few of on the shelf, because a wheel end that is already apart should never sit waiting on a gasket.

At FleetPro Parts & Tires, we know an axle job is only right when every seal in it is new. This Automann gasket is a direct replacement for highly searched industry numbers including Eaton 6823, Meritor R002431, Spicer 7284, Volvo/White 476075 and Mack 130SP19.

Vehicle Fitment & Compatibility

This drive axle flange gasket uses a universal design intended for the following commercial applications:

• Make/Model: Universal - Freightliner and other Class 8 trucks and tractors
• Position: Drive axle flange joint at the wheel end
• Axle Numbers Covered: Eaton, Meritor, Spicer, Mack, Ford, IHC and Volvo/White
• Component Group: Air Brake & Wheel / Wheel End Seals & Bearings
• Service Note: Clean the sealing surfaces and torque the flange bolts to spec in sequence

Direct Replacement & Cross-Reference Numbers:

This Automann drive flange gasket serves as a direct replacement for the following part numbers:

• Eaton Interchange: 6823
• Meritor Interchange: R002431
• Spicer Interchange: 7284
• Mack Interchange: 130SP19
• Ford Interchange: B3TZ1001A
• IHC Interchange: 115135H
• Volvo/White Interchange: 476075, 716743
• Automann Distributor #: 180.10610

Technical Specifications

• Component Type: Drive Axle Flange Gasket
• Application: Universal
• Weight: 0.03 lbs
• Package Dims: 8.5 x 8.5 x 0.043 in
• UPC: 889626045448
• Product Level: Fleet Standard Aftermarket
• Brand: Automann (Distributed by FleetPro Parts & Tires)
