Gladhand Service Blue - 38 Degree Angle Bottom Mount Trailer - Grote 81-0001-38B Phillips 12-136 PHI12-136
Regular price
$11.58
Couldn't load pickup availability
- Ships same dayOn in-stock orders
- 30-day money-backShop with confidence
- Secure checkoutEncrypted payment
We accept
Fitment
Fits these trucks
Commercial trailers - nose/bottom mountTrailer-side service (blue) air brake line38 degree angle, bottom mount (trailer side)Connects service (blue) and emergency (red) air lines
Always confirm your year, make & model before ordering.
Part numbers
OEM & interchange numbers
9 cross-refsGrote 81-0001-38B Grote 81000138B Phillips 12-136 Phillips 12136 Tectran 16091 Tectran 9217 Tramec Sloan 441023 Tramec Sloan 56161 Velvac 035092
Direct 1-to-1 replacement for every number above. Tap any number to copy.
Overview
Put a proper coupling back on the trailer nose with this OE Phillips Blue Service Gladhand distributed by FleetPro Parts & Tires. It is the 38 degree angle, bottom mount version built for the trailer side, carrying the service (blue) air line that sends the foot-brake signal to the trailer brakes. A cracked gladhand body or a worn seal seat is the first place to look for the hiss you hear at hookup, and it is the reason the system is slow to build, the low-air warning stays on, and an inspector has something to write down. We stock these heavily right here in our Hanover Park, Illinois warehouse to ensure lightning-fast shipping for fleets, trailer repair shops, and owner-operators nationwide.
A Coupling That Stops Leaking: The Phillips Angle Mount Gladhand Advantage
This is a genuine Phillips gladhand built to SAE J318, so it couples correctly with every standard gladhand on the road, tractor or trailer. The 38 degree angle, bottom mount geometry is what makes it a trailer-side part: the body sits at the angle the nose plate expects, and the 3/8in NPT female port faces down so the air line drops away cleanly instead of being forced into a stress bend right at the fitting.
The blue body and the offset locking lugs are the industry standard that keeps the service line from being cross-coupled to the red emergency line. Replace the whole gladhand rather than just the seal when the casting is cracked or the seal seat is worn flat, because a chewed-up seat will destroy a fresh seal in weeks and you will be back under the trailer chasing the same leak. At FleetPro Parts & Tires, we know air brake work has to pass inspection the first time. This Phillips gladhand is a direct replacement for highly searched industry numbers including Grote 81-0001-38B, Phillips 12-136, Tectran 16091, Tramec Sloan 441023 and Velvac 035092.
Vehicle Fitment & Compatibility
This OE-supplier gladhand is intended for the following commercial applications:
- Make/Model: Universal - commercial trailers and Class 8 tractor-trailer air systems
- System: Connects the service (blue) and emergency (red) air lines at the tractor-trailer hookup
- Mount: 38 degree angle, bottom mount, for use on the trailer
- Port: 3/8in NPT female, bottom
- Component Group: Air Brake & Wheel / Gladhands & Accessories
Direct Replacement & Cross-Reference Numbers:
This Phillips gladhand serves as a direct replacement for the following part numbers:
- Grote Interchange: 81-0001-38B, 81000138B
- Phillips Interchange: 12-136, 12136
- Tectran Interchange: 16091, 9217
- Tramec Sloan Interchange: 441023, 56161
- Velvac Interchange: 035092
- Automann Distributor #: PHI12-136
Technical Specifications
- Component Type: Service (Blue) Gladhand Coupling
- Line: Blue (service)
- Port: 3/8in NPT female, bottom
- Mount: 38 degree angle, bottom mount (trailer side)
- Compliance: SAE J318
- Weight: 0.72 lbs
- Package Dims: 4 x 4 x 2.75 in
- UPC: 889626600067
- Product Level: OEM
- Brand: Phillips (Distributed by FleetPro Parts & Tires)
Key features
- Trailer-Side Angle Mount: The 38 degree angle bottom mount matches the trailer nose plate, so the coupling sits where the driver reaches for it.
- Genuine Phillips OE Build: An Original Equipment gladhand, not a thin copy that cracks the first winter it gets dropped on a deck plate.
- SAE J318 Coupling: Mates correctly with every standard gladhand on the road, so it works on any tractor that backs under the trailer.
- Bottom 3/8in NPT Port: The air line drops away cleanly instead of being forced into a stress bend right at the fitting.
- Cures a Worn Seal Seat: Replacing the whole gladhand fixes the chewed seat that eats a brand new seal in a matter of weeks.
Specifications
Component Type
Service (Blue) Gladhand Coupling
Line
Blue (service)
Port
3/8in NPT female, bottom
Mount
38 degree angle, bottom mount (trailer side)
Compliance
SAE J318
Weight
0.72 lbs
Package Dims
4 x 4 x 2.75 in
UPC
889626600067
Product Level
OEM
Questions
Will this fit my truck?
This part fits Commercial trailers - nose/bottom mount, Trailer-side service (blue) air brake line, 38 degree angle, bottom mount (trailer side), Connects service (blue) and emergency (red) air lines. Always confirm your year, make and model before ordering.
What part numbers does it replace?
Yes. It is a direct replacement that interchanges with Grote 81-0001-38B, Grote 81000138B, Phillips 12-136, Phillips 12136, Tectran 16091, Tectran 9217, Tramec Sloan 441023, Tramec Sloan 56161, Velvac 035092.
How fast does it ship?
In-stock orders placed before 12 PM Central on business days ship the same day from our Hanover Park, IL warehouse, and typically arrive in 2 to 5 business days anywhere in the USA.
What's your return policy?
Unused items in original packaging can be returned within 30 days, backed by our 30-day money-back guarantee. If we ship the wrong part, we cover the return label and send the correct one.
