OEM Radar Cover for AERO CLAD Bumper - Freightliner Cascadia 2018-2025 - 66-06345-000

Only 2 left
SKU: 66-06345-000
$16.79
  • Ships same dayOn in-stock orders
  • 30-day money-backShop with confidence
  • Secure checkoutEncrypted payment
We acceptAmazon American Express Apple Pay Diners Club Discover Google Pay Mastercard Shop Pay Visa

If you have a large order and would like to get a discount, please fill out this form.

Fitment

Fits these trucks

Freightliner New Cascadia (P4, 2018-2025) with the Hendrickson AERO CLAD bumperTrucks with a front radar collision-avoidance sensorRadar-area cover panel for the AERO CLAD conversion
Always confirm your year, make & model before ordering.
Part numbers

OEM & interchange numbers

1 cross-ref
Freightliner 66-06345-000
Direct 1-to-1 replacement for every number above. Tap any number to copy.
Overview

Finish the AERO CLAD conversion properly with this genuine Freightliner OEM radar cover. It is the steel cladding panel that installs at the front radar location when an OEM plastic bumper is converted to the Hendrickson AERO CLAD system, protecting the bumper structure and framing the opening for the forward collision-avoidance radar. Leave that opening improvised and the sensor sits unshielded and out of position, which is exactly how a truck starts throwing collision-mitigation and adaptive-cruise faults on a clear road. We stock these right here in our Hanover Park, Illinois warehouse to ensure lightning-fast shipping for fleets, truck body shops, and owner-operators nationwide.

Radar Where It Belongs: The AERO CLAD Cover Advantage

This is a steel panel, painted black, measuring approximately 304 mm long by 93 mm high and 3 mm thick โ€” a genuine cladding piece rather than a bracket bent up in a shop. Steel at the radar location is what takes the gravel, salt spray and impact energy that the front of a Class 8 truck lives in, and the factory dimensions keep the sensor correctly located so the collision-mitigation and adaptive-cruise features read the road accurately instead of reporting faults.

This is the radar-area cover panel for the AERO CLAD conversion. If you are converting a truck from the OEM plastic bumper to AERO CLAD, plan on the bumper screens, the screen mounting brackets and the radar mount bracket as well โ€” the conversion needs all of them, and finding that out mid-job with the bumper already off is how a two-hour install turns into an overnight. This part is a direct replacement for the highly searched Freightliner number 66-06345-000.

Vehicle Fitment & Compatibility

This genuine Freightliner cover is intended for the following commercial application:

  • Make/Model: Freightliner New Cascadia (P4), 2018 to 2025
  • Bumper: Trucks equipped with the Hendrickson AERO CLAD bumper
  • Requirement: Trucks with a front radar collision-avoidance sensor
  • Also Required for Conversion: Bumper screens, screen mounting brackets and radar mount bracket
  • Component Group: Front Bumper / Radar Cladding

Direct Replacement & Cross-Reference Numbers:

This genuine cover serves as a direct replacement for the following part number:

  • Freightliner Interchange: 66-06345-000

Technical Specifications

  • Component Type: AERO CLAD Bumper Radar Cover
  • Material: Steel
  • Color: Black
  • Finish: Painted
  • Length: approx. 304 mm
  • Height: approx. 93 mm
  • Thickness: approx. 3 mm
  • Brand: Freightliner (Distributed by FleetPro Parts & Tires)
Key features
  • Keeps the Radar Correctly Located: Frames the opening for the forward collision-avoidance radar so the sensor stays shielded and in position and reads accurately.
  • Steel Cladding Panel: Painted steel takes the gravel, spray and impact energy that live at the front of a Class 8 truck.
  • Genuine Freightliner OEM: The factory radar cover for the AERO CLAD conversion, not a shop-fabricated filler panel.
  • Protects the Bumper Structure: Covers and shields the bumper structure at the radar location instead of leaving the opening exposed.
  • Built for the AERO CLAD System: The correct panel when an OEM plastic bumper is converted to the Hendrickson AERO CLAD bumper.
Specifications
Component Type
AERO CLAD Bumper Radar Cover
Material
Steel
Color
Black
Finish
Painted
Length
approx. 304 mm
Height
approx. 93 mm
Thickness
approx. 3 mm
Also Required for Conversion
Bumper screens, screen mounting brackets and radar mount bracket
Questions
Will this fit my truck?
This part fits Freightliner New Cascadia (P4, 2018-2025) with the Hendrickson AERO CLAD bumper, Trucks with a front radar collision-avoidance sensor, Radar-area cover panel for the AERO CLAD conversion. Always confirm your year, make and model before ordering.
What part numbers does it replace?
Yes. It is a direct replacement that interchanges with Freightliner 66-06345-000.
How fast does it ship?
In-stock orders placed before 12 PM Central on business days ship the same day from our Hanover Park, IL warehouse, and typically arrive in 2 to 5 business days anywhere in the USA.
What's your return policy?
Unused items in original packaging can be returned within 30 days, backed by our 30-day money-back guarantee. If we ship the wrong part, we cover the return label and send the correct one.
