Oval Marker LED Light with Chrome Bezel - 2 x 6.5 in Amber 4-Diode - Grote 45582 45583 571.LD27A4M1
Oval Marker LED Light with Chrome Bezel - 2 x 6.5 in Amber 4-Diode - Grote 45582 45583 571.LD27A4M1
Automann

Oval Marker LED Light with Chrome Bezel - 2 x 6.5 in Amber 4-Diode - Grote 45582 45583 571.LD27A4M1

In stock
SKU: 571.LD27A4M1
$17.42
  • Ships same dayOn in-stock orders
  • 30-day money-backShop with confidence
  • Secure checkoutEncrypted payment
We acceptAmazon American Express Apple Pay Diners Club Discover Google Pay Mastercard Shop Pay Visa

If you have a large order and would like to get a discount, please fill out this form.

Fitment

Fits these trucks

Universal - Class 8 Trucks, Commercial Trailers, Utility VehiclesScrew mount with M1 chrome bezel, 4.5 in C2C holesP/T marker positions12V electrical systems
Always confirm your year, make & model before ordering.
Part numbers

OEM & interchange numbers

7 cross-refs
Grote 45582 Grote 45583 Optronics 00212335 Optronics 00212335P Optronics 00212337 Optronics 00212337P 212335
Direct 1-to-1 replacement for every number above. Tap any number to copy.
Overview

Finish a universal marker or clearance position the right way with this 2 x 6.5 in Oval LED Marker Lamp in amber, distributed by FleetPro Parts & Tires, built with its own chrome-plated ABS bezel already in place. A pitted, rusted or cracked original comes off and a finished assembly goes on in one step โ€” no separate trim ring to source. A faded marker lens is both an inspection item and the thing everyone at the truck stop notices first. Manufactured by Automann to Fleet Standard specifications, this lamp is stocked heavily right here in our Hanover Park, Illinois warehouse for lightning-fast shipping to fleets, diesel repair shops, and owner-operators nationwide.

Finished Look, Legal Light: The M1 Chrome Bezel Advantage

The oval lamp body measures 2 in x 6.5 in and runs four diodes behind an amber polycarbonate lens set in the chrome ABS bezel. It is an M1 type assembly with 4.5 in center-to-center mounting holes, and it feeds through a .180 molded bullet connector on a 12V circuit, so the swap is a screw-and-plug job rather than a splice. Photometrics meet SAE P2 and FMVSS 108. Being an LED, it draws less current and has no filament to break when the frame flexes over a rough crossing.

At FleetPro Parts & Tires, we know that compliance is king. This Automann lamp is a direct replacement for highly searched industry numbers including Grote 45582 and 45583, plus Optronics 00212335, 00212335P, 00212337 and 00212337P.

Vehicle Fitment & Compatibility

This heavy-duty aftermarket LED lamp uses a universal design intended for the following commercial applications:

  • Make/Model: Universal Class 8 Trucks, Commercial Trailers, and Utility Vehicles
  • Function: P/T marker
  • Mounting Style: Screw mount, M1 type bezel, 4.5 in C2C mounting holes
  • System Requirement: 12V Electrical Systems, .180 molded bullet connector
  • Component Group: Exterior Lighting / Marker & Clearance Lamps

Direct Replacement & Cross-Reference Numbers:

This Automann LED marker lamp serves as a direct replacement for the following part numbers:

  • Grote Interchange: 45582, 45583
  • Optronics Interchange: 00212335, 00212335P, 00212337, 00212337P
  • Additional Interchange: 212335
  • Automann Distributor #: 571.LD27A4M1

Technical Specifications

  • Component Type: Oval LED Marker Lamp with Chrome Bezel
  • Size & Shape: 2 in x 6.5 in Oval
  • Lens Material: Amber Polycarbonate with Chrome ABS Bezel
  • Diode Count: 4
  • Voltage: 12V
  • Connector: .180 Molded Bullet
  • Mount: Screw, M1 Bezel
  • Mounting Holes: 4.5 in C2C
  • Compliance: SAE P2, FMVSS 108
  • Weight: 0.2 lbs
  • Package Dims: 8.562 x 3.843 x 1.562 in
  • Product Level: Fleet Standard Aftermarket
  • Brand: Automann (Distributed by FleetPro Parts & Tires)
Key features
  • Chrome Bezel Included: The chrome-plated ABS bezel ships with the lamp, so a corroded original is replaced by a finished assembly in one step.
  • M1 Type, 4.5 in C2C: Standard M1 geometry and 4.5 in center-to-center holes line up with the existing screw pattern.
  • Plug-In .180 Bullet: The molded bullet connector turns the job into a screw-and-plug swap instead of a splice.
  • Amber Polycarbonate Lens: Polycarbonate resists stone strikes and wash-bay pressure that craze softer lenses.
  • SAE P2 and FMVSS 108: Photometrics meet the standards checked at inspection, so the marker keeps the truck legal.
Specifications
Component Type
Oval LED Marker Lamp with Chrome Bezel
Size & Shape
2 in x 6.5 in oval
Lens Material
Amber polycarbonate with chrome ABS bezel
Diode Count
4
Function
P/T marker
Voltage
12V
Connector
.180 molded bullet
Mount
Screw, M1 bezel
Mounting Holes
4.5 in C2C
Compliance
SAE P2, FMVSS 108
Weight
0.2 lbs
Package Dims
8.562 x 3.843 x 1.562 in
UPC
889626373404
Product Level
Fleet Standard Aftermarket
Questions
Will this fit my truck?
This part fits Universal - Class 8 Trucks, Commercial Trailers, Utility Vehicles, Screw mount with M1 chrome bezel, 4.5 in C2C holes, P/T marker positions, 12V electrical systems. Always confirm your year, make and model before ordering.
What part numbers does it replace?
Yes. It is a direct replacement that interchanges with Grote 45582, Grote 45583, Optronics 00212335, Optronics 00212335P, Optronics 00212337, Optronics 00212337P, 212335.
How fast does it ship?
In-stock orders placed before 12 PM Central on business days ship the same day from our Hanover Park, IL warehouse, and typically arrive in 2 to 5 business days anywhere in the USA.
What's your return policy?
Unused items in original packaging can be returned within 30 days, backed by our 30-day money-back guarantee. If we ship the wrong part, we cover the return label and send the correct one.
