Fleetguard Secondary Fuel Filter - Volvo D11/D13/D16 & Mack MP7/MP8 Pre-2017 - Replaces 20430751 Baldwin BF7814 FF5507

The Fleetguard FF5507 is the OEM secondary, or final, spin-on fuel filter used on Volvo and Mack Class 8 trucks, and it is the last thing standing between your fuel tank and a set of injectors. It protects the high-pressure fuel system from the fine contamination the primary filter lets through, and when it is neglected the truck tells you: fuel restriction, low power, and injector damage that costs many times what the filter does. We stock these heavily right here in our Hanover Park, Illinois warehouse to ensure lightning-fast shipping for fleets, diesel repair shops, and owner-operators nationwide.

Final-Stage Filtration: The FF5507 Advantage

This is Cummins Filtration's own captive-brand filter, engineered to Volvo and Mack OEM spec and installed both on the assembly line and across the dealer service counter. The cellulose media runs outside-in for final-stage duty on high-pressure common-rail and unit-injector systems, and the can is built to the factory envelope: M32 x 1.5-6H thread, 10.39 in (263.9 mm) height, 4.24 in largest OD, and a 3.94 in / 3.56 in gasket. It spins onto the pre-2017 Volvo and Mack filter head with no adapter.

One number covers a lot of iron. At FleetPro Parts & Tires we like a part that simplifies the shelf: this filter serves Volvo D11, D13 and D16 and Mack MP7, MP8 and MP10, and it is a direct replacement for highly searched industry numbers including Baldwin BF7814, Donaldson P550529, WIX 33721, Luber-Finer LFF8059, NAPA 3721 and the Volvo/Mack OE number 20430751. Always replace it alongside the primary fuel filter.

Vehicle Fitment & Compatibility

This OE-grade secondary fuel filter is intended for the following commercial applications:

• Engines: Volvo D11, D13 and D16; Mack MP7, MP8 and MP10 (pre-2017)
• Make/Model: Volvo VNL, VNM and VHD; Mack Pinnacle, Granite, TerraPro and Titan
• Position: Secondary / final fuel filtration, outside-in flow
• System: High-pressure common-rail and unit-injector fuel systems
• Service Note: Replace together with the primary fuel filter

Direct Replacement & Cross-Reference Numbers:

This Fleetguard fuel filter serves as a direct replacement for the following part numbers:

• Baldwin Interchange: BF7814, BK6650, BK6656, BK6956
• Donaldson Interchange: P550529, P550739, P559106
• WIX Interchange: 33721, 24656, 24980, WS10113, 24039, 95037E
• Luber-Finer Interchange: LFF8059
• Fram Interchange: P9626
• NAPA / Carquest Interchange: 3721, 86721
• Hengst Interchange: H200WDK
• Volvo Interchange: 20430751, 20976003, 20405160, 20815011
• Mack Interchange: 20539582, 20972295, 20976005, 85114535
• Fleetguard Part #: FF5507

Technical Specifications

• Component Type: Spin-On Secondary (Final) Fuel Filter
• Flow Direction: Outside-in
• Media: Cellulose
• Thread: M32 x 1.5-6H
• Height: 10.39 in (263.9 mm)
• Largest OD: 4.24 in (107.7 mm)
• Gasket OD / ID: 3.94 in / 3.56 in
• Product Level: OE (Original Equipment)
• Brand: Fleetguard (Distributed by FleetPro Parts & Tires)
