Fleetguard Secondary Oil Filter - Volvo D13 & Mack MP8 2017+ - Replaces Volvo 21707132 Baldwin B7409 LF17502
Fleetguard Secondary Oil Filter - Volvo D13 & Mack MP8 2017+ - Replaces Volvo 21707132 Baldwin B7409 LF17502
Fleetguard

Fleetguard Secondary Oil Filter - Volvo D13 & Mack MP8 2017+ - Replaces Volvo 21707132 Baldwin B7409 LF17502

In stock
SKU: LF17502
$26.99
  • Ships same dayOn in-stock orders
  • 30-day money-backShop with confidence
  • Secure checkoutEncrypted payment
We acceptAmazon American Express Apple Pay Diners Club Discover Google Pay Mastercard Shop Pay Visa

If you have a large order and would like to get a discount, please fill out this form.

Fitment

Fits these trucks

Volvo D13 and Mack MP8, 2017 and newerVolvo D11 and VED13; Mack MP7 and MP10 (2007+)Volvo VNL, VNM, VNR and VNX; Mack Pinnacle, Granite, Anthem, CHU and CXUSecondary spin-on lube filter - part of the D13/MP8 oil-change kit
Always confirm your year, make & model before ordering.
Part numbers

OEM & interchange numbers

16 cross-refs
Baldwin B7409 Baldwin B7685 Donaldson P550425 WIX WL10106 WIX 51660 Luber-Finer LFP8642 NAPA 400106 Carquest 96322 Hastings LF675 Fram P9407 Hengst H200WN01 Volvo 21707132 Volvo 21170573 Mack 21707132 Mack 21707135 Fleetguard LF3654
Direct 1-to-1 replacement for every number above. Tap any number to copy.
Overview

The Fleetguard LF17502 is the spin-on secondary lube filter that finishes the job the full-flow filter starts on a Volvo or Mack heavy-duty diesel. It polishes the oil the primary passes, holding back the soot and fine wear metal that turn a healthy bottom end into a rebuild. It is the filter commonly supplied in the Volvo D13 and Mack MP8 full-service oil-change kit alongside its full-flow companion. We stock these heavily right here in our Hanover Park, Illinois warehouse to ensure lightning-fast shipping for fleets, diesel repair shops, and owner-operators nationwide.

Cleaner Oil, Longer Bottom End: The LF17502 Advantage

The cellulose media is rated 16 micron (c) at 98.7% efficiency, and the can is built to the engine's own envelope: 1-3/8"-16 UNF, 2B thread, 10.24 in (260 mm) height, 4.31 in (109.6 mm) outer diameter, and a 3.70 in / 4.02 in gasket. A minimum hydrostatic burst rating of 246.5 psi means the housing takes a cold-start pressure spike in stride. There is no pressure relief valve in this filter, which is correct for the secondary position on these engines.

At FleetPro Parts & Tires, we sell the filter that came off the line, not a lookalike. This is a genuine Cummins Filtration part that replaces Volvo and Mack OE 21707132 and supersedes the earlier Fleetguard LF3654, and it is a direct replacement for highly searched industry numbers including Baldwin B7409, Donaldson P550425, WIX WL10106, Luber-Finer LFP8642, NAPA 400106, Carquest 96322 and Hastings LF675. It is typically installed with Fleetguard LF17503, FS19765 and FF42128NN for a complete D13/MP8 service.

Vehicle Fitment & Compatibility

This OE-grade secondary lube filter is intended for the following commercial applications:

  • Engines: Volvo D13 and Mack MP8, 2017 and newer
  • Also Fits: Volvo D11 and VED13; Mack MP7 and MP10 (2007+)
  • Make/Model: Volvo VNL, VNM, VNR and VNX; Mack Pinnacle, Granite, Anthem, CHU and CXU
  • Position: Secondary spin-on lube (oil) filter
  • Service Kit: Installed with Fleetguard LF17503, FS19765 and FF42128NN

Direct Replacement & Cross-Reference Numbers:

This Fleetguard lube filter serves as a direct replacement for the following part numbers:

  • Volvo Interchange: 21707132, 21170573
  • Mack Interchange: 21707132, 21707135
  • Fleetguard Interchange: LF3654 (superseded by this filter)
  • Baldwin Interchange: B7409, B7685
  • Donaldson Interchange: P550425
  • WIX Interchange: WL10106, 51660
  • Luber-Finer Interchange: LFP8642
  • NAPA / Carquest Interchange: 400106, 96322
  • Hastings Interchange: LF675
  • Fram Interchange: P9407
  • Hengst Interchange: H200WN01
  • Fleetguard Part #: LF17502

Technical Specifications

  • Component Type: Spin-On Secondary Lube (Oil) Filter
  • Media: Cellulose
  • Efficiency: 16 micron (c) @ 98.7%
  • Thread: 1-3/8"-16 UNF, 2B
  • Height: 10.24 in (260 mm)
  • Outer Diameter: 4.31 in (109.6 mm)
  • Gasket ID / OD: 3.70 in / 4.02 in
  • Hydrostatic Burst (min): 246.5 psi
  • Pressure Relief Valve: No
  • Product Level: OE (Original Equipment)
  • Brand: Fleetguard (Distributed by FleetPro Parts & Tires)
Key features
  • Bypass-Side Protection: The secondary filter polishes oil the full-flow filter passes, holding 16 micron (c) at 98.7% to keep soot and wear metal away from the bearings.
  • Genuine Cummins Filtration Part: Fleetguard is the factory filtration brand for these engines, so the thread, gasket and can height seal like the original.
  • Replaces Volvo/Mack 21707132: A direct swap for the Volvo and Mack OE number, and it supersedes the older Fleetguard LF3654.
  • 246.5 psi Burst Strength: A 246.5 psi minimum hydrostatic burst rating means the can takes cold-start oil pressure spikes instead of splitting.
  • Part of the Full Service Kit: Pairs with Fleetguard LF17503, FS19765 and FF42128NN for a complete D13/MP8 service in a single order.
Specifications
Component Type
Spin-On Secondary Lube (Oil) Filter
Media
Cellulose
Efficiency
16 micron (c) @ 98.7%
Thread
1-3/8"-16 UNF, 2B
Height
10.24 in (260 mm)
Outer Diameter
4.31 in (109.6 mm)
Gasket ID / OD
3.70 in / 4.02 in
Hydrostatic Burst (min)
246.5 psi
Pressure Relief Valve
No
Supersedes
Fleetguard LF3654
Product Level
OE (Original Equipment)
Questions
Will this fit my truck?
This part fits Volvo D13 and Mack MP8, 2017 and newer, Volvo D11 and VED13; Mack MP7 and MP10 (2007+), Volvo VNL, VNM, VNR and VNX; Mack Pinnacle, Granite, Anthem, CHU and CXU, Secondary spin-on lube filter - part of the D13/MP8 oil-change kit. Always confirm your year, make and model before ordering.
What part numbers does it replace?
Yes. It is a direct replacement that interchanges with Baldwin B7409, Baldwin B7685, Donaldson P550425, WIX WL10106, WIX 51660, Luber-Finer LFP8642, NAPA 400106, Carquest 96322, Hastings LF675, Fram P9407, Hengst H200WN01, Volvo 21707132, Volvo 21170573, Mack 21707132, Mack 21707135, Fleetguard LF3654.
How fast does it ship?
In-stock orders placed before 12 PM Central on business days ship the same day from our Hanover Park, IL warehouse, and typically arrive in 2 to 5 business days anywhere in the USA.
What's your return policy?
Unused items in original packaging can be returned within 30 days, backed by our 30-day money-back guarantee. If we ship the wrong part, we cover the return label and send the correct one.
